Transformer
Dimmable with triac forward and reverse phase, 0/1-10V , resistor, PWM
Temperature class B(130°C)
Housing
The actual transformer 60W is encapsulated in the enclosure
The enclosure is Plastic suitable for dry and damp location, IP20, wire
compartment is optional rated
Enclosure Temperature does not exceed 65°C at 45°C ambient and fully loaded
Dimensions (inch): H = 2.4, W = 7.6, D = 0.95
Weight (LBs): 0.66
Electrical Parameters
Input Voltage: 100-277V 50/60Hz
Max. input current at full load: 0.78A
Output voltage without load: 65VDC
Output voltage fully loaded: VDC
Max. Total Wattage: 60W
Max. Output Current: 2.1A
Efficiency: 83%
